Yunyi Diesel Fuel Tank Level Sensor 4-20mA SS304 Oil Tank Level Sensor

  • 1
  • 2

Brand Name : Yunyi

Model Number : YD322

Certification : CE

Place of Origin : China

MOQ : 1

Price : 35-68.50usd

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 1000/month

Delivery Time : 5-7 days

Packaging Details : carton or wooden box

Name : Yunyi Diesel Fuel Tank Level Sensor 4-20mA SS304 Oil Tank Level Sensor

Sensor material : SS316

Cable material : PE, PU, PTFE

Sensor dia : 27mm

Power : 10…36V DC;5V

Output : 4-20mA, 0-5V, 0-10V, RS485

Accuracy : +/-0.5%FS

Overload : 200%

Work temp : 0-60C

Protection : IP68

Measure range : 0-100m

Contact Now

Yunyi Diesel Fuel Tank Level Sensor 4-20mA SS304 Oil Tank Level Sensor

1. Main advantages
High precision and stability
Adopt diffused silicon or ceramic capacitor sensors, with an accuracy of ±0.1%FS, good long-term stability, suitable for continuous monitoring.
Easy installation
Directly put into the bottom of the liquid or fixed depth, no complex structure required, suitable for pools, deep wells, tanks and other scenes.
Strong environmental adaptability
Corrosion resistance: The probe can be made of polytetrafluoroethylene (PTFE), Hastelloy and other materials, suitable for acid, alkali, seawater and other media.
Anti-clogging: No mechanical moving parts, suitable for sewage, oil, viscous liquids.
Wide temperature range: Some models support -40℃～125℃ environment.
Low maintenance cost
No moving parts, less wear, long life, only need to clean the probe daily.
Multi-function output
Support analog (4-20mA), digital signal (RS485/MODBUS), wireless transmission (LoRa/NB-IoT), etc., compatible with PLC/DCS system.

Specification of Submersible Level Transmitter 4-20mA rs485 level sensor

Pressure Span 0...1…500mH2O
Output Signal 4...20mA
Supply Input 10…36V DC
Accuracy +/-0.5%FS
Non-Linearity +/-0.250% FS
Repeatability +/-0.10% FS
Thermal Error +/-0.2% FS/oC
Zero Drift +/-0.25% FS
Long Term Stability +/-0.5% FS/Year
Over Pressure Safety 200%
Operating Temperature 0oC to 50oC
Response Time <1ms (10-90%FS)
Diaphragm titanium alloy Stainless Steel
Case Material 316L Stainless Steel
Compatibility Liquid compatible with titanium alloy
Protection IP68
